Carbo
Activated-carbon module for deodorizing air polluted with volatile organic compounds.
The Carbo range
The Carbo modular filter unit consists of activated-carbon cartridges aimed at deodorizing air polluted with volatile organic compounds. It is typically used together with the Clean pocket-filter module, which acts as a dust prefilter ahead of the activated carbon; for deodorization or absorption of airborne chemicals or solvents — such as during painting or plastics processing — air passes through the Carbo unit connected to the Clean module. The activated carbon is contained in cylinders made of micro-perforated wire mesh, allowing easy replacement of the carbon. Modular construction and high filter efficiency allow filtered air to be reintroduced into the work environment for energy savings.
- Modular construction
- High filter efficiency
- Energy savings by reintroducing filtered air into the work environment
- High-retention activated carbon in easily replaceable micro-perforated mesh cylinders
At a glance
Carbo specifications
| Model | Filter type | Activated carbon (kg) | Max flow (m³/h) | Max flow (cfm) | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
| Carbo 21 | Activated carbons | 20 | 1500 | 882 | 700 | 350 | 700 | 635 | 285 | 48 |
| Carbo 22 | Activated carbons | 40 | 3000 | 1765 | 700 | 700 | 700 | 635 | 635 | 88 |
| Carbo 42 | Activated carbons | 80 | 6000 | 3529 | 1400 | 700 | 700 | 1335 | 635 | 96 |
| Carbo 62 | Activated carbons | 120 | 9000 | 5294 | 2100 | 700 | 700 | 2035 | 635 | 140 |
| Carbo 82 | Activated carbons | 160 | 12000 | 7058 | 2800 | 700 | 700 | 2735 | 635 | 160 |
| Carbo 102 | Activated carbons | 200 | 15000 | 8823 | 3500 | 700 | 700 | 3435 | 635 | 250 |
| Carbo 44 | Activated carbons | 160 | 12000 | 7058 | 1400 | 1400 | 700 | 1335 | 1335 | 176 |
| Carbo 64 | Activated carbons | 240 | 18000 | 10588 | 2100 | 1400 | 700 | 2035 | 1335 | 150 |
| Carbo 84 | Activated carbons | 320 | 24000 | 14117 | 2800 | 1400 | 700 | 2735 | 1335 | — |
| Carbo 104 | Activated carbons | 400 | 30000 | 17647 | 3500 | 1400 | 700 | 3435 | 1335 | — |
Pollutants captured
